Mineral Cement Jumbo Bagging Machine Ton Bag Packing Machine Automatic
Contact Person : Yark Wang
Phone Number : 86-18020515386
WhatsApp : +8618020515386
Minimum Order Quantity : | 1 | Price : | Negotion |
---|---|---|---|
Packaging Details : | Plywood Box | Delivery Time : | 30 days |
Payment Terms : | T/T, L/C, Western Union, MoneyGram | Supply Ability : | 100 sets |
Place of Origin: | China | Brand Name: | JL |
---|---|---|---|
Model Number: | DCS-TB |
Detail Information |
|||
Name: | Sugar Sand Salt Bulk Bag Filler | Warranty Of Core Parts: | 1 Year |
---|---|---|---|
Voltage: | 380V 50Hz | After Warranty Service: | Spare Parts |
Packing Speed: | 30-50 (bags/hour) | Weight Range: | 500kg ~ 2000kg |
Power: | 6.5KW | Packaging Error: | ≤± 0.2% |
Temperature: | -20-40℃ | Key Selling Points: | High-accuracy |
High Light: | 1 Ton Jumbo Bagging Machine,6.5 KW Jumbo Bagging Machine Filling System,Sugar Sand Salt Bulk Bag Filler |
Product Description
1 Ton big bag filling system sugar sand salt bulk bag filler
Application
It’s suitable for granules or powders product like Glucose, monosodium glutamate, starch, coal powder, pebble, paste block, polyethylene, PVC additive, polyester chip, potassium chloride, potassium sulfate, ammonium sulfate, zinc oxide, adipic acid, bleaching powder, etc
Key Technology
1. Auto free drop course feeding and fine feeding
2. Parameters can be freely adjusted during running condition
3. Self-diagnose function on the electronic boards
4. Compact 304 SUS body design and build
5. Intelligent control panel for easy operate and clean
6. High precision digital load cell
7. Color touch screen (Mouse, SD card and memory card are compatible)
8. Multi-language choice (Translation is needed for some specific language)
9. Different authority management
Technical Parameter
Weighing range | 500-2000 (kg/bag) |
Quantitative error | ±0.2%FS |
Packing speed | 30-50 (bags/hr) (depending on material characteristics, bag size, bag mouth size, etc.) |
Main Features
1. The weighing system adopts electronic weighing platform scale type measurement, imported digital weighing instrument, adopts comprehensive digital adjustment and parameter setting, with weighing cumulative display, automatic tare, automatic zero calibration, automatic drop correction, out of tolerance alarm and failure Self-diagnosis function, high sensitivity and strong anti-interference ability
2. Using PLC program control, the communication interface can be configured according to user needs, which is convenient for online networking and implements real-time monitoring and network management
3. Using gravity feeding or screw feeding method to improve working accuracy and speed
4. After the packaging is completed, it will be automatically separated from the bag clamp and bag hanging mechanism without other operations. It can be transported to the next process by a conveyor such as belt conveyor,roller conveyor or chain conveyor.
5. Advanced dust-proof and dust-removal design to reduce dust pollution in the working environment
6. It can be equipped with bag shaking function or flexibly adjust the height of bag clamping machine and hook
7. The on-site installation of this equipment is more flexible and convenient. It can be adapted to local conditions to a large extent, and the location can be arranged reasonably, and special processing and manufacturing can be combined with user requirements and actual conditions on site to meet the requirements of use conditions
