Semi automatic bag opener bag slitter bag slitting and emptying machine

Product Description

Semi automatic bag opener bag slitter bag slitting and emptying machine

Product overview:

The bag slitting and emptying machine is used for unpacking and unloading bagged granular materials. The machine is widely used in automatic bagging and unloading of dry powdered materials in the fields of chemical, petroleum, building materials, metallurgy, electricity, food, medicine, food, environmental protection, etc. It can do automatic bagging and unloading of materials such as nitrolime, magnesium oxide, quartz sand, limestone, sawdust, protein powder, activated carbon, milk powder, PVC powder, fly ash, urea, clay, gypsum, cement, sewage treatment additive powder, etc. It uses a belt conveyor to automatically feed the bags, a cutting device to automatically break the bags, a chain conveyor and a receiving hopper to separate the bag materials, and the materials fall into the receiving hopper by gravity to complete the bag dismantling and unloading work. This machine improved the working environment greatly for workers by unsing its built-in dust removal device to filter and purify the dust generated during operation.

Technical parameters:

Technical Specification:

• Max. Capacity: 500 bags/hour
• Bag empty rate: 99.00% - 99.99%
• Power: 4 KW
• Power supply: 415V, 50Hz, 3 phases
• Power air volume: 1500-2000 m³/hour
• Body material: The part in contact with the material is made of SUS304, and the rest is made of carbon steel
• Dust collector: SUS 304
• Belt conveyor: Rubber strip, carbon steel frame
• Waste bag rolling-out machine: carbon steel

Machine Specification:

Bag sizes up to 700mm x 400mm x 145mm (Weight – 50Kgs/bag)

Emptying efficiency – 98% – 99% depending on flowing characteristics of the material

Particle sizes: Powder & pellets of free flow characteristics.
