Automatic Bag Slitting Machine Process Belt Conveyor 800bags Hour

Product Description

Belt Conveyor Automatic Bag Slitting Machine

Description

This machine is suitable for BOPP, OPP thermal contraction film heat sealing. Heat sealing cut is suitable for making socks bag, towel bag, bread bag, jewelry bag, express bag this machine has power and fixed length, photoelectric tracking, stable performance, fast, with automatic gluing, automatic hole and other functions.

Automatic bag slitting machine is mainly composed of belt conveyor and main machine. The main machine is composed of base, cutter box, drum screen, screw conveyor, waste bag collector and dust removal device.

The bagged materials are transported to the slide plate by the belt conveyor, and slide along the slide plate by gravity. During the sliding process, the packaging bag is cut by fast rotating blades, and the cut residual bags and materials slide into the drum screen for screening. The materials dropped from the drum screen are output by screw conveyor, and the damaged packaging bags, impurities and caking materials are taken out of the body by the drum screen. The dust caused in the process of cutting knife breaking bag is collected by bag filter and shaken into screw conveyor through pulse control system (the materials output from screw conveyor can be transported to material storage tank by pipe chain conveyor or pneumatic conveying device).

Technical Specification

MoC – Available in mild steel construction with optional coatings & stainless steel with optional finishes.

Capacity: 100 to 800 bags/hour of 25 to 50 kg.

Type of bags: Except Jute made, all other material bags

Material Retention: 2% maximum

Machine Specification:

Bag sizes up to 700mm x 400mm x 145mm (Weight – 50Kgs/bag)

Emptying efficiency – 98% – 99% depending on flowing characteristics of the material

Particle sizes: Powder & pellets of free flow characteristics.

Technical parameters:

About us

      Wuxi Jianlong Packaging Co., Ltd. is a R & D and production enterprise specializing in solid material packaging solution. Our product portfolio includes bagging scales and feeders, open mouth bagging machines, valve bag fillers, jumbo bag filling machine, automatic packing palletizing plant, vacuum packaging equipment, robotic and conventional palletizers, stretch wrappers, conveyors,telescopic chute, flow meters, etc. Wuxi Jianlong has a group of engineers with strong technical strength and rich practical experience, which can help customers with one-stop service from solution design to product delivery, freeing workers from the heavy or unfriendly working environment, improving production efficiency, and will also create considerable economic returns for customers.

Wuxi Jianlong offers a wide range of knowledge about packaging machines and related ancillary equipment, bags and products, as well as packaging automation solutions. Through the careful testing of our professional technology and R & D team, we are committed to providing perfect customized solutions for every customer. We combine the international quality with the Chinese local market to provide an ideal automatic / semi-automatic, environmental friendly and efficient automatic packaging system. We are constantly striving to provide customers with intelligent, clean and economical packaging equipment and industrial 4.0 solutions by combining rapid localization service and spare parts delivery.

No matter what solutions we offer you, such as material characteristic analysis, packaging bag analysis or feeding, conveying, filling, packaging, palletizing, automatic design and turnkey engineering, we are looking forward to be your reliable long-term partner.
