PLC Valve Bag Cement Filling Machine AC 380V Easy Operation

Minimum Order Quantity : 1 set Price : Negotion
Packaging Details : plywood box Delivery Time : 30 days
Payment Terms : T/T, L/C, Western Union, MoneyGram Supply Ability : 100 sets
Place of Origin: China Brand Name: JL

Detail Information

Name: Valve Bag Cement Filling Machine Accuracy Level: +/-0.5%
Key Selling Point: Easy Operation Core Components: PLC
Weighing Range: 5 ~ 50kg / Bag Packing Speed: 150-200 Bags / Hour
Working Power Supply: AC 380V/50Hz 60W (Or According To The Customer's Requirement) Function: Filling, Sealing
Aggregate In Packaging Materials: ≤Φ5mm Condition: Brand New
High Light:

Valve Bag Cement Filling Machine

,

PLC Valve Bag Filling Machine

,

AC 380V Valve Bag Filling Machine

Product Description

Valve Bag Cement Filling Machine Cement Bag Packing Machine Cement Packaging Machinery





How it Works:



The valve bag is installed on the fill spout, and rests in the bag chair mechanism. When the clamshell gate opens, product gravity flows into the bag. When the bag has reached the designated weight, the clamshell gate closes, and the bag can be removed.



Valve bag filler details:



Gravity Fed Valve Bag Filler

For free-flowing, granular and pelleted materials

Fertilizer, Corn, Soybeans, Salt, Sugar

Sand, Limestone, Refractory Materials, Plastic Pellets

Fill valve bags

Fill rate of 1 – 3 bags / minute

Automatically fill 20 – 110 pound bags

Material is fed by gravity through the gravity gate into a funnel spout and into the bag

No air or electricity is required for basic operation and is an automatic gross weighing filler that simultaneously fills and weighs product directly into the bag.

Includes machine controls, scale, dust collection, bag clamp and more

Custom options available upon request

1 year limited warranty.



Valve filling machine DCS-VBGF adopts gravity flow feeding, which has the characteristics of high packaging speed, high stability and low power consumption



Technical Parameters:



Applicable materials powder or granular materials with good fluidity
Material feeding method gravity flow feeding
Weighing range 5 ~ 50kg / bag
Packing speed 150-200 bags / hour
Measurement accuracy ± 0.1% ~ 0.3% (related to material uniformity and packaging speed)
Air source 0.5 ~ 0.7MPa Gas consumption: 0.1m3 / min
Power supply AC380V, 50Hz, 0.2kW





PLC Valve Bag Cement Filling Machine AC 380V Easy Operation 0

PLC Valve Bag Cement Filling Machine AC 380V Easy Operation 1PLC Valve Bag Cement Filling Machine AC 380V Easy Operation 2
